1-1. Remove the Door As
How To Change Door Position
1-2. Reverse the Door Accessories
a. Remove 'Top Cover Hinge' and 'Top Hinge'
b. Separate 'Refrierator Door'.
c. Remove 'Middle Hinge'
d. Separate 'Freezer Door'.
e. Remove 'Cover Bracket'.
f. Remove 'Under Hinge'.
g. Reverse the position of 'Cover Bushing
Refrigeraor Door'
- Unscrew and remove 'Harness Cover'.
- Take out 'Left Door Harness' and assemble
'Harness Cover' on 'Right Door Harness'.
h. Reverse the position of 'Cover Bushing
Freezer Door'.
i. Reverse the position of 'Door Stoppers'.
ⓑ
ⓓ
J. Reverse the position of 'Button Switch'.
- Unscrew 'Button Switch'
ⓙ
ⓖ
ⓗ
25
