Relationship between cable diameter (24V AC) and transmission distance 19
Relationship between Cable Diameter (24V AC) and Transmission Distance Appendix 3
The recommended transmission distances are for reference only, and the actual conditions
shall prevail.
For Cameras powered by alternating current, the maximum voltage lose rate allowed is 10%.
For example, when a device of 20 W rated power is installed 141 inches (42m) away from the
transformer, the minimum diameter needed is 0.8000 mm.
Transmission
power (W)
Diameter (mm)
0.8000
1.000
1.250
2.000
Transmission distance Feet (m)
5
488.52 (148.90)
763.31 (232.66)
1192.67 (363.53)
3053.25 (930.63)
10
244.26 (74.45)
381.66 (116.33)
596.34 (181.76)
1526.62 (465.31)
15
162.84 (49.63)
254.44 (77.55)
397.56 (121.18)
1017.75 (310.21)
20
122.13 (37.23)
190.83 (58.16)
298.17 (90.88)
763.31 (232.66)
25
97.70 (29.78)
152.66 (46.53)
238.53 (72.71)
610.65 (186.13)
30
81.42 (24.82)
127.22 (38.78)
198.78 (60.59)
508.87 (155.10)
35
69.79 (21.27)
109.04 (33.24)
170.38 (51.93)
436.18 (132.95)
40
61.06 (18.61)
95.41 (29.08)
149.08 (45.44)
381.66 (116.33)
45
54.28 (16.54)
84.81 (25.85)
132.52 (40.39)
339.25 (103.40)
50
48.85 (14.89)
76.33 (23.27)
119.27 (36.35)
305.32 (93.06)
55
44.41 (13.54)
69.39 (21.15)
108.42 (33.05)
277.57 (84.60)
60
40.71 (12.41)
63.61 (19.39)
99.39 (30.29)
254.44 (77.55)
65
37.58 (11.45)
58.72 (17.90)
91.74 (27.96)
234.87 (71.59)
70
34.89 (10.64)
54.52 (16.62)
85.19 (25.97)
218.09 (66.47)
75
32.57 (9.93)
50.89 (15.51)
79.51 (24.24)
203.55 (62.04)
80
30.53 (9.31)
47.71 (14.54)
74.54 (22.72)
190.83 (58.16)
85
28.74 (8.76)
44.90 (13.69)
70.16 (21.38)
179.60 (54.74)
90
27.14 (8.27)
42.41 (12.93)
66.26 (20.20)
169.62 (51.70)
95
25.71 (7.84)
40.17 (12.25)
62.77 (19.13)
160.70 (48.98)
100
24.43 (7.45)
38.17 (11.63)
59.63 (18.18)
152.66 (46.53)
