Dahua XVR SERIES User Manual

3
2 The Grand Tour for Rear Panel
The following figure shows the rear panel of model with 16 video input ports (as an example).
No.
Port Name
No.
Port Name
No.
Port Name
1
Ground
6
HDMI port
11
VGA port
2
Alarm input/output port,
ground
7 USB port 12 Power button
3 Video input port 8 Network port 13 Power cable fastener
4 Audio input port 9
RS
485 communication
port
5 Audio output port 10 Power input port
Table 2-1

Dahua XVR SERIES Specifications

General

Brand	Dahua
Model	XVR SERIES
Category	DVR
Language	English
