14 Configuration
Installer and user reference guide
19
BRC1H519W+K+S
Wired remote controller
4P513689-1A – 2018.03
Remote controller field settings
Mode SW SW description Value Default value
R1 3 Controller thermistor adjustment
(Cooling)
0: –3.0°C, 1: –2.5°C,
2: –2.0°C, 3: –1.5°C,
4: –1.0°C, 5: –0.5°C,
6: ±0°C, 7: +0.5°C,
8: +1.0°C, 9: +1.5°C,
10: +2.0°C, 11: +2.5°C,
12: +3.0°C
6
4 Controller thermistor adjustment
(Heating)
0: –3.0°C, 1: –2.5°C,
2: –2.0°C, 3: –1.5°C,
4: –1.0°C, 5: –0.5°C,
6: ±0°C, 7: +0.5°C,
8: +1.0°C, 9: +1.5°C,
10: +2.0°C, 11: +2.5°C,
12: +3.0°C
6
5 Controller thermistor adjustment (Auto) 0: –3.0°C, 1: –2.5°C,
2: –2.0°C, 3: –1.5°C,
4: –1.0°C, 5: –0.5°C,
6: ±0°C, 7: +0.5°C,
8: +1.0°C, 9: +1.5°C,
10: +2.0°C, 11: +2.5°C,
12: +3.0°C
6
6 Controller thermistor adjustment (Fan
only)
0: –3.0°C, 1: –2.5°C,
2: –2.0°C, 3: –1.5°C,
4: –1.0°C, 5: –0.5°C,
6: ±0°C, 7: +0.5°C,
8: +1.0°C, 9: +1.5°C,
10: +2.0°C, 11: +2.5°C,
12: +3.0°C
6
7 Home screen 0: Detailed
1: Standard
1
8 Backlight no-operation timer 0: 5 seconds
1: 10 seconds
2: 20 seconds
0
9 Status indicator faintness 0: 0% (OFF), 1: 1%,
2: 2%, 3: 3%,
4: 5%, 5: 7%,
6: 9%, 7: 11%,
8: 13%, 9: 15%,
10: 17%, 11: 20%
9
10 Backlight faintness 0: 0% (OFF), 1: 1%,
2: 2%, 3: 3%,
4: 4%, 5: 5%,
5
11 Status indicator mode 0: Normal
1: Hotel setting 1
2: Hotel setting 2
2
13 Bluetooth Low Energy advertising 0: Always advertising
1: Enable manually
0
R2 1 Touch button indicator (on screen) 0: None
1: Small
2: Medium
3: Large
1
Status indicator mode (R1-11)
Remote controller field setting R1-11 allows for the status indicator
to be set to a mode suitable for use in hotels. According to the value
that is set for this setting, the status indicator has the following
behaviour:
Operation state Status indicator behaviour
0 (Normal) 1 (Hotel setting 1) 2 (Hotel setting 2)
Operation ON ON ON ON (when the backlight goes into
faint state, the status indicator
turns OFF)
Operation OFF OFF OFF OFF
