Specifications SiAU18-715
24 Specifications
1.2.2 BP Units
50Hz 220-240V
Note:
1. BP or Indoor Unit Max. Height - BP or Indoor Unit Min. Height
→
Max. 15m.
Set up BP and indoor unit within 15m height difference.
2. The piping connection must be cut so as to suit the piping sizes of the indoor unit which will be connected.
The same sizes should be used for the piping on the outdoor unit.
3. ( )* : including auxiliary piping length
Model BPMKS967A2 BPMKS967A3
Connectable Indoor Units 1~2 Units 1~3 Units
Casing Color Paintingless
Power Consumption W 10 10
Running Current A 0.05 0.05
Refrigerant Type R-410A
Dimension (H×W×D) mm 180×294(650)*×350
Package Dimension (H×W×D) mm 257×738×427
Machine Weight kg 7.5 8
Gross Weight kg 11 12
Number of Wiring Connections 4 for Interunit Wiring
Piping
Connection
(Brazing)
Liquid mm Main :
φ
9.5×1 / Branch :
φ
6.4×2 Main :
φ
9.5×1 / Branch :
φ
6.4×3
Gas mm Main :
φ
19.1×1 / Branch :
φ
15.9×2 Main :
φ
19.1×1 / Branch :
φ
15.9×3
Drain mm Drain Processingless
Heat Insulation Both Liquid and Gas Pipes
Max. Piping Length m —
Amount of Additional Charge g/m —
Max. Height Difference m —
Max. Combination kW 14.2 20.8
Min. Combination kW 2.5 2.5
Accessories
Installation Manual pc. 1
L Shape Reducer pc.
For Main
Liquid 1 (For I.D.
φ
6.4)
Gas 1 (For I.D.
φ
12.7)
Gas 1 (For I.D.
φ
15.9, 19.1)
For Branch
Liquid 2 (For I.D.
φ
12.7, 9.5) 3 (For I.D.
φ
12.7, 9.5)
Gas 1 (For I.D.
φ
9.5)
Hanger Metal pc. 4
Screws pc. 8 (M4×8)
Heat Insulation (2pc. is 1 set) 3 Set 4 Set
Binding Band pc. 2
Drawing No. 4D050057B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
