ESIE15-11A | Part 3. Field settings 3. Wired remote controller BRC1D51/52
23/09/16 Page 27
VRV4 indoor units
3. Wired remote controller BRC1D51/52
3.1. Access field settings
1. When in the normal mode, press the “ ” button for a minimum of four seconds, and the FIELD SET MODE is entered.
2. Select the desired MODE NO. with the “ ” button.
3. During group control, when setting by each indoor unit (mode No. 20, 21, 22 and 23 have been selected), push the “ ”
button and select the INDOOR UNIT NO. to be set. (This operation is unnecessary when setting by group.)
4. Push the “ ” upper button and select FIRST CODE NO.
5. Push the “ ” lower button and select the SECOND CODE NO.
6. Push the “ ” button once and the present settings are SET.
7. Push the “ ” button to return to the NORMAL MODE.
