Daikin LRYEQ16A7Y1 User Manual

LRYEQ16A7Y1 + LCBKQ3AV1(E)
CONVENI-PACK
4P448940-1A – 2016.07
Operation manual
14
10. PRODUCT MODELS AND MAIN SPECIFICATIONS
10-1Models and Main Specifications.
Note:
• Operating conditions:
Outdoor unit
(Air-conditioning side) Indoor temperature: 27°CDB/19°CWB, Outdoor temperature: 32°CDB, Piping
length: 7.5m, Level difference: 0m (In cooling priority mode)
(Cooling equipment side) Evaporating temperature: -10°C, Outdoor temperature: 32°CDB, Suction SH:
10°C (In cooling priority mode)
(Heating conditions) Indoor temperature: 20°CDB, Outdoor temperature: 7°CDB/6°CWB, Cooling equip-
ment load: 18 kW,
Piping length: 7.5 m, Level difference: 0 m
Saturated temperature equivalent to suction pressure (Cooling equipment side) : -10°C (Under chilled
condition),
Connection capacity for indoor air-conditioner: 10HP, When heat recovery is 100%
Sound pressure level is less than 70 dB(A).
Booster unit
Evaporating temperature: -35°C, Outdoor temperature: 32°C, Suction SH: 10°C, Saturated temperature
to discharge pressure of booster unit: -10°C
• The figures for the outside unit models show values measured at a distance of 1 m in the front and a
height of 1.5 m.
Values measured with the models actually installed are usually larger then the values shown as a result
of ambient noise and reflections.
When the outdoor temperature is low, the temperature reading may be below the target evaporating tem-
perature set for the protection of the unit.
• Values are subject to change without notice for product improvements.
• The "E" suffix indicates anti-corrosion models.
Model LRYEQ16A7Y1 LCBKQ3AV1 (E)
Power supply 3 phase 380~415V 50Hz 1 phase 220~240V 50Hz
Refrigerant R410A
Operating condition
Evaporating temperature -20°C~10°C (Refrigeration) -45°C~-20°C
Outdoor
temperature
Refrigeration -15°C~43°CDB
-15°C~43°CDB
Cool -5°C~43°CDB
Heat
-15°C~21°CDB
-15°C~15.5°CWB
Capacity (kW)
Cool
Air-conditioning 14 -
Refrigerating 21.8 -
Freezing - 3.35
Heat
Air-conditioning 27 -
Refrigerating 21.8 -
Freezing - 3.35
Outer dimensions (HxWxD) (mm) 1680×1240×765 480×680×310
Product mass (kg) 370 47
Sound pressure level (dB(A)) 62 49
Design pressure
High-pressure
side
(bar) 40 38
(MPa) 4.0 3.8
Low-pressure
side
(bar) 25 25
(MPa) 2.5 2.5
4PEN448940-1A.book Page 14 Thursday, August 25, 2016 11:23 AM
