Carbon lter unit
Cannot be washed with water
The carbon lter unit
acts as a safety
switch, because if it
is removed, UV
emission is
impossible.
After cleaning, be
sure to attach it
before operation.
When dirt becomes
an issue
Vacuum cleaner
When odor and dirt
becomes an issue
Expose to air ow
in a shady place
How to remove
Hold the lever of the carbon lter unit and the grip,
and pull it out.
Lever
Grip
How to attach
Push the carbon lter unit all the way in.
Press until a catching
sound is heard
• If the carbon lter unit or the carbon lter is not
attached properly, the odor sensor lamp or
the UV ON/OFF lamp blinks.
• Remove the entire frame from the unit, then
vacuum away dust using a vacuum cleaner.
• If odor becomes a problem, expose to airow in
a shady place. (Approx. 1 day)
• Do not rub the surface.
• Do not wash with water. (If you wash it with
water, it will lose its shape and you will not be
able to use it.)
►
Page 21
Do not remove the carbon
lter from the frame
• If odor and dirt are still an issue even after
cleaning, replace it.
About purchase and disposal
• Refer to “Replacement Parts”
►
Page 25
• For the attachment method, refer to “Attaching
the carbon lter”
►
Page 11
Dust collection lter
Cannot be washed with water
Dust collection lter
Replace
Do not vacuum clean
About replacement timing
• When the lter replacement lamp lights up,
there is about 1 month remaining before
replacement is necessary.
• When the lter replacement lamp blinks,
replace the dust collection lter with a new one.
Please consider replacing the carbon lter at
the same time.
After replacing the dust collection lter with a
new one, press and hold
and
simultaneously for about 2 seconds to reset the
lter replacement alert.
(Two short beeps will sound, and the lter
replacement lamp will turn off.)
About purchase and disposal
• Refer to “Replacement Parts”
►
Page 25
How to remove
1
Remove the carbon lter unit.
Dust collection lter
2
Lift the tag of the dust
collection lter up.
3
Hold the bottom of the dust
collection lter and pull it out.
How to attach
1
Paying attention to the orientation, install a
new dust collection lter.
The side with the tag and
marking is the front side,
and the tip of the arrow
points to the top side
2
Attach the carbon lter unit.
Note
• The replacement timing of the dust collection
lter depends on how it is used and the usage
environment.
WARNING
•
Do not use gasoline, benzine, thinner, polishing compound, parafn, alcohol, etc. (Cracking, electric shock, and ignition of re may result)
• Do not wash the unit with water. (Electric shock and re or malfunctioning may result)
Attention
Be sure to operate with a dust collection lter, and carbon lter unit attached.
If the unit is operated without the lters attached, malfunction may result.
