6 | Unit installation
Installer reference guide
24
CVXM20A + FVXM25~50A
Split system air conditioners
4P625991-1C – 2021.09
≤60
(65)
≤27°
(mm)
≥467
≥50 ≥50
A B
(105)
≤60
A Front view
B Side view
▪ Do not install the unit more than 60mm above the floor.
6.2 Opening the indoor unit
6.2.1 To remove the front panel
1 Slide both sliders in the direction of the arrows until they click.
2 Open the front panel and remove the string.
3 Remove the front panel.
6.2.2 To remove the front grille
1 Remove the front panel. See "6.2.1To remove the front panel"[424].
2 Remove the 4 screws, remove the grille from 4 tabs on the top and remove
the front grille while pulling it toward you.
