5
Display
SET
MTuWThF
SaSu
AM
PM
Morning
Evening
Day
Night
HEAT
COOL
FILTER
88
12:00
1
Day of the week. When programming, MTuWThF represent the
five weekdays and SaSu represent the two weekend days.
2
Heat and Cool indicators. In normal operation, Heat or Cool
appears, depending on the Mode Switch position. When heat
or cool is energized, the Heat or Cool indicator will flash.
3
Clock Display.
4
Time period indicators. These indicate the part of the
program that is currently active, if the Program Switch
is positioned to RUN.
5
Desired set temperature.
6
Current room temperature.
7
Indicates when the filter should be serviced. Appears
after 0 - 1950 hours of blower operation (adjustable).
8
Indicates batteries need replacement.
