Install the top cover
1. Hook the top cover at the front edge on the front cover.
2. Secure the top cover using a screw on each side. Use 2 x cross
head screws.
If the top cover does not align
with the side cover plates it may
be necessary to drill new 3 mm
holes:
1. Mark for the new holes
2. Lift off the top cover
3. Drill the holes
3. Install and screw the top cover into place
Install stand cover
1. Hook the cover onto the stand.
Installation Guide Domestic heat pumps
Danfoss Heating Solutions VMGFQ102
15
