Menu selection Meaning Factory setting
CURVE -5 Local increase or reduction of CURVE at an outdoor temperature of -5°C. Shown in the graph
for CURVE.
0°C(range: -5°C / 5°C)
HEAT STOP Maximum outdoor temperature when heat production is permitted.
If HEAT STOP applies, the outdoor temperature must drop 3°C below the setting before
HEAT STOP stops.
17°C(range: , 0°C /
40°C)
REDUCTION Only appears if the tariff control function has been activated. Lowering set room tempera-
ture. Active at 10 kΩ connection at EVU input.
2°C(range: 1°C / 10°C)
TANK TEMP Displayed if buffer tank is active. Charges the buffer tank to the set temperature. AUTO set-
ting charges the tank to the supply line setpoint value.
AUTO(range: AUTO,
30°C / 55°C)
OVERCHARGE Displayed if the buffer tank is active and TANK TEMP is set to AUTO. Charges the buffer tank
to supply line setpoint value + the value of OVERCHARGE.
0°C(range: 0°C / 5°C)
ROOM FAC-
TOR
Only displayed if an accessory Room temperature sensor is installed.
Determines how great an impact the room temperature is to have when calculating the sup-
ply temperature. For under floor heating it is recommended that ROOM FACTOR is set to 1, 2
or 3. For radiator heating it is recommended that ROOM FACTOR is set to 2, 3 or 4.(0 = no
impact, 4 = very large impact)
2(range: 0 / 4)
POOL (Expan-
sion card)
Only appears if POOL is selected. The temperature in the pool is controlled by a separate sen-
sor regardless of the heating and hot water system.
20°C(range: , 5°C /
40°C)
POOL HYSTE-
RESIS(Expan-
sion card)
Only appears if POOL is selected. The difference between the desired charge value (adjusta-
ble) and actual value to the pool sensor. Pool hysteresis does not affect the integral value.
2°C(range: 1°C / 10°C)
8.3 Sub-menu HEAT CURVE 2
Only appears if shunt group sensor is connected and activated in menu SERVICE -> INSTALLATION - SYSTEM -> SHUNT GROUP.
Menu selection
Meaning Factory setting
CURVE 2 Calculated shunt group temperature at 0°C outdoor temperature. Shown as a graphic curve.
The curve will be limited by the set values of MIN and MAX.
40°C(range: 22°C / 56°C)
MIN Minimum permitted shunt group temperature, if the temperature for heat stop has not
been reached.
10°C(range: 10°C / 50°C)
MAX Maximum permitted shunt group temperature. 55°C(range: 15°C / 70°C)
8.4 Sub-menu TEMPERATURE
The history of different temperature measurements can be viewed by pressing the right arrow key. The graph shows the last 60 meas-
urement points for the set time interval (SERVICE -> INSTALLATION -> LOG TIME). In the event of an alarm, history stops being logged
until the alarm is reset by changing the operating mode to OFF.
Menu selection
Meaning Factory
setting
OUTDOOR Shows the actual outdoor temperature. -
ROOM Shows the actual set temperature. -
SYSTEM SUPPLY Displays system supply temperature at the buffer tank system. -
SUPPLY LINE Shows the actual supply temperature. The calculated supply temperature to the heating system group
is within brackets.
During hot water production in operating mode AUX. HEATER the value for HOT WATER STOP + 10° is
shown within brackets.
-
RETURN LINE Shows the actual return temperature. The stop temperature, MAX RETURN is within brackets. -
BUFFER TANK Indicates the buffer tank temperature, if activated. -
HOT WATER Indicates actual hot water temperature, if activated. -
INTEGRAL Shows the actual calculated value for integral. -
BRINE IN Shows the actual temperature for brine in. -
Installation Guide Domestic heat pumps
VMGFQ102 Danfoss Heating Solutions
40
