6 Electrical Installation
DANGER! Electrical voltage! The terminal blocks are live and can be highly dangerous due to the risk of
electric shock. All power supplies must be isolated before electrical installation is started. The heat pump
is connected internally at the factory, for this reason electrical installation consists mainly of the
connection of the power supply.
Caution! Electrical installation may only be carried out by an authorized electrician and must follow
applicable local and national regulations.
Caution! The electrical installation must be carried out using permanently routed cables. It must be
possible to isolate the power supply using an all-pole circuit breaker with a minimum contact gap of 3
mm. (The maximum load for externally connected units is 2A).
6.1 Electrical components
1 2 3
5
7
6
4
8
9
121110
Figure 38. The location of the components on
the electrical panel
Symbol explanation
1 Terminal block (applies to the expansion card)
2 Terminal block (applies to DHP-A)
3 Defrost card (applies to DHP-A)
4 Terminal block
5 Space for Danfoss Online
6 Warning decal
7 Space for expansion card
8 Motor protection for compressor
9 Automatic fuses
10 Resetting overheating protection
11 Control computer
12 Soft starter card
6.2 Fuse size
DHP-H, DHP-H Opti, DHP-H Opti Pro, DHP-L, DHP-L Opti, DHP-L Opti Pro
4 kW 6 kW 8 kW 10 kW 12 kW 16 kW
400V, 3-N A
16
8
/10
1
/10
2
/16
3
10
1
/16
2
/20
3
16
1
/16
2
/20
3
16
1
/16
2
/20
3
16
1
/20
2
/25
3
20
1
/20
2
/25
3
230V, 1-N A
20
1
/25
2
/32
3
25
1
/32
2
/40
3
25
1
/32
2
/40
3
32
1
/40
2
/50
3
32
1
/40
2
/50
3
-
DHP-C
6 kW 8 kW 10 kW 4 H 5 H 7 H
400V, 3-N A
10
1
/16
2
/20
3
16
1
/16
2
/20
3
16
1
/16
2
/20
3
10
1
/16
2
/20
3
16
1
/16
2
/20
3
16
1
/16
2
/20
3
