■ Quick Setup via Quick menu
The Quick Setup starts with pressing the [QUICK
MENU] key, which brings out the following read-out
on the display:
At the bottom of the display, the parameter number
and name are given together with the status/value of
the first parameter under Quick Setup. The first time
the [Quick Menu] key is pressed after the unit has
been switched on, the read-outs will always start at
pos. 1 - see table below.
■ Parameter selection
The selection of parameter is effected by means of
the [+/-] keys. The following parameters are accessible:
Pos.:No.: Parameter: Unit:
1 001 Language
2 200 Direction of rotation
3 101 Torque characteristic
4 204 Min. reference [Hz]
5 205 Max. reference [Hz]
6 207 Ramp up time [sec.]
7 208 Ramp down time [sec.]
8 002 Local/remote control
9 003 Local reference
10 500 Bus address
• Read-out state III:
This read-out state can be held as long as the
[DISPLAY/STATUS] key is pressed. When the key is
released, the system switches back to Read-out state
II, unless the key is pressed for less than approx. 1
sec..
This is where parameter names and units for
operating variables in the first line are given -
operating variable 2 remains unchanged.
■ Quick menu mode versus Menu mode
The FC motor series can be used for practically all
assignments, which is why the number of
parameters is quite large. Also, this series offers a
choice between two programming modes - a Menu
mode and a Quick menu mode.
• The Quick menu takes the user through a
number of parameters that may be enough to get
50.0 HZ
50.0 HZ
SETUP
1
SETUP
1
MOTOR IS RUNNING
REF% TORQUE CURR A
QUICK MENU X OF Y
001 LANGUAGE
ENGLISH
Local Control
the motor to run nearly optimally, if the factory setting
for the other parameters takes the desired control
functions into account, as well as the configuration of
signal inputs/outputs (control terminals).
• The Menu mode makes it possible to select and
change all parameters at the user's option.
However, some parameters will be "missing", depending
on the choice of configuration (parameter 100), e.g.
open loop hides all the PID parameters.
In addition to having a name, each parameter is linked
up with a number which is the same regardless of the
programming mode. In the Menu mode, the
parameters are divided into groups, with the first digit of
the parameter number (from the left) indicating the
group number of the parameter in question.
Regardless of the mode of programming, a change of
a parameter will take effect and be visible both in the
Menu mode and in the Quick menu mode.
• Read-out state II:
Switching between read-out states I and II is
effected by pressing the [DISPLAY / STATUS] key.
In this state, data values for four operating values
are shown at the same time, giving the related unit,
cf. table. In the example, Reference, Torque,
Current and Frequency are selected as variables in
the first and second line.
MOTOR IS RUNNING
50.0 HZ
24.3% 30.2% 13.8A
