© Danfoss A/S (AC-SMC/MWA), 08-2011 DKRCI.PI.HV0.E6.02 / 520H3832 6
Service
Description ICV Name Min Max Factory
Setting
Stored Unit Pass word Comments
OD % ¡50 0 100 - % - ICM valve Opening Degree
AI [mA] ¡51 0 100 - mA - AI signal
AI [V] ¡52 0 100 - V - AI signal
AO [mA] ¡53 0 100 - mA - A0 signal
DI ¡54 0 1 - - - DI signals. Depending of ¡02
If ¡02 = 2, one digits are shown. See g. 8
0 : DI1 = OFF
1 : DI1 = ON
If ¡02 = 3, two digits are shown. See g. 9
00 : DI1 = OFF, DI2 = OFF
10 : DI1 = ON, DI2 = OFF
01 : DI1 = OFF, DI2 = ON
11 : DI1 = ON, DI2 = ON
DO Close ¡55 0 1 - - - DO Closed status. ON when OD < 3 %
DO Open ¡56 0 1 - - - DO Open status. ON when OD > 97 %
DO Alarm ¡57 0 1 - - - DO alarm status. ON when a Alarm is detected
Display mP SW ver. ¡58 0 100 - - - Software version for display microprocessor
Motor mP SW ver. ¡59 0 100 - - - Software version for motor microprocessor
Reset to factory setting:
1. Remove the power supply.
2. Activate down arrow and up arrow push buttons
at the same time.
3. Connect the power supply.
4. Release down arrow and up arrow push buttons.
5. When the display on ICAD (g. 2) is alternating
between showing: CA and A1 the factory
resetting is complete.
