Class ID 0x06 Connection Manager
Attribute Access Name Data Type Description
1 Get Open Requests UINT Number of Forward Open requests received
2 Get Open Format Rejects UINT Number of Forward Open requests rejected due to bad
format
3 Get Open Resource Rejects UINT Number of Forward Open requests rejected due to lack of
resources
4 Get Open Other Rejects UINT Number of Forward Open requests rejected due to other
reasons
5 Get Close Requests UINT Number of Forward Close requests received
6 Get Close Format Requests UINT Number of Forward Close requests rejected due to bad
format
7 Get Close Other Requests UINT Number of Forward Close requests rejected due to other
reasons
8 Get Connection Timeouts UINT Number of connection timeouts
9 Get Connection Entry List Struct of:
NumConnEntries
INT Number of connection entries ConnOpenBits ARRAY of BOOL
List of connection data
Table 8.3 Instance Attributes
Class ID 0x28 Motor Data Object
Attribute Access Name Data Type Parameter Description
1 Get Number of Attributes supported USINT - 7
2 Get List of attributes supported Array of USINT - 3,6,7,8,9,12,15
3 Get/Set Motor Type USINT 1-10 3: PM sync. motor (FC 302 only)
7: Squirrel cage induction motor
6 Get/Set Rated Current UINT 1-24 Unit: 100 mA
7 Get/Set Rated Voltage UINT 1-22 Unit: Volt
8 Get/Set Rated Power UDINT 1-20 Unit: Watt
9 Get/Set Rated Frequency UINT 1-23 Unit: Hertz
12 Get/Set Pole Count UINT 1-39 Number of poles in motor
15 Get/Set Base Speed UINT 1-25 Unit: RPM
Table 8.4 Instance Attributes
NOTE
Class ID 0x28 is only available if ODVA profile is selected in 8-10 Control Word Profile.
Appendix MCA 121 EtherNet/IP
MG.90.J3.02 - VLT
®
is a registered Danfoss trademark 45
8 8
