3.1.2 MCD5-0068B - MCD5-0105B (G1B)
1 3
4
5 6
8
9
10
2
7
11
177 HA5 37.10
1 Cover 7 Current transformers
2 Cable guide 8 Mounting posts
3 Main plastic 9 SCRs
4 Terminal blocks 10 Side plastic
5 LCP and Main Control PCB 11 Fan
6 Model PCB
MCD 500 Service Manual 3 Service Instructions
MG.17.L1.02 - VLT
®
is a registered Danfoss trademark
15
3
