2.1.6. Overview Menu Section B
The table below gives an overview of the menu structure. The two menu levels are clearly indicated
by an arrow followed by a submenu. The values shown are only intended as examples of display
texts.
The display text (shown in the first column Display Functions ) is divided between 2 lines, with 16
characters available per line. The line division is illustrated with the symbol |.
Menu Structure B
Display Functions Description
Operation mode | STANDBY
Displays present inverter operation mode. See operation mode definitions
in chapter 2.
PV configuration | IDLE
Shows the status of the automatic PV configuration test and the results
found.
Event: Mod. | ENS FL. CH DCAC
If the inverter is not connected to the grid because of a failure, the red
LED starts flashing, and the reason for the failure is shown here.
Language | ENGLISH View and choose display language. Does not affect any other settings.
Grid voltage | 0 V Displays the present grid AC voltage.
Grid current | 0.00 A Displays the present current flow to the grid.
Grid frequency | 0.00 Hz Displays the present grid frequency.
Grid impedance | 0.0 ohm Displays the present grid impedance.
PV voltage | Press OK to view Press OK to access submenu for recorded values.
↳
Submenu
PV voltage no. 1 | 303.0 V Present voltage at PV input 1 (upper position in inverter).
PV voltage no. 2 | 303.0 V Present voltage at PV input 2 (second position in inverter)*.
PV voltage no. 3 | 303.0 V Present voltage at PV input 3 (third position in inverter)*.
PV current | PRESS OK to view Press OK to access submenu for recorded values.
↳
Submenu
PV current no. 1 | 0.0 A Present current at PV input 1 (upper position in inverter).
PV current no. 2 | 0.0 A Present current at PV input 2 (second position in inverter)*.
PV current no. 3 | 0.0 A Present current at PV input 3 (third position in inverter)*.
Maximum values | Press OK to view Press OK to access submenu for recorded values.
↳
Submenu
AC out: 1844 W | 8.356 A 263 V
Maximum values recorded at AC output since last resetting of max. value
memory.
DC1 in: 2220 W** | 8.004 A 509 V
Maximum values recorded at DC1 input since last resetting of max. value
memory.
DC2 in: 2220 W** | 8.004 A 509 V
Maximum values recorded at DC2* input since last resetting of max. value
memory.
DC3 in: 2220 W** | 8.004 A 509 V
Maximum values recorded at DC3* input since last resetting of max. value
memory.
Table 2.3: Overview Menu Structure B
*) The PV2 and PV3 menus are only displayed in inverters equipped with two or three inputs.
2. Function Description
L00410362-05_2q 7
2
