Danfoss VLT AutomationDrive FC 300 Series Operating Instructions

UL compliance
Enclosure FC 300 power Recommended
fuse size
Recommended
max. fuse
Recommended circuit
breaker
Max trip level
Size [kW] Moeller [A]
A1 0.25-1.5 gG-10 gG-25 PKZM0-16 16
A2 0.25-2.2 gG-10 (0.25-1.5)
gG-16 (2.2)
gG-25 PKZM0-25 25
A3 3.0-3.7 gG-16 (3)
gG-20 (3.7)
gG-32 PKZM0-25 25
B3 5.5 gG-25 gG-63 PKZM4-50 50
B4 7.5-15 gG-32 (7.5)
gG-50 (11)
gG-63 (15)
gG-125 NZMB1-A100 100
C3 18.5-22 gG-80 (18.5)
aR-125 (22)
gG-150 (18.5)
aR-160 (22)
NZMB2-A200 150
C4 30-37 aR-160 (30)
aR-200 (37)
aR-200 (30)
aR-250 (37)
NZMB2-A250 250
A4 0.25-2.2 gG-10 (0.25-1.5)
gG-16 (2.2)
gG-32 PKZM0-25 25
A5 0.25-3.7 gG-10 (0.25-1.5)
gG-16 (2.2-3)
gG-20 (3.7)
gG-32 PKZM0-25 25
B1 5.5-7.5 gG-25 (5.5)
gG-32 (7.5)
gG-80 PKZM4-63 63
B2 11 gG-50 gG-100 NZMB1-A100 100
C1 15-22 gG-63 (15)
gG-80 (18.5)
gG-100 (22)
gG-160 (15-18.5)
aR-160 (22)
NZMB2-A200 160
C2 30-37 aR-160 (30)
aR-200 (37)
aR-200 (30)
aR-250 (37)
NZMB2-A250 250
Table 3.26 200-240 V, Frame Sizes A, B, and C
