5. General Specifications
Line power supply (L1, L2, L3):
Supply voltage FC 302: 380-500 V ±10%
Supply voltage FC 302: 525-690 V ±10%
Supply frequency 50/60 Hz
Max. imbalance temporary between line phases 3.0% of rated supply voltage
True Power Factor (λ) ≥ 0.9 nominal at rated load
Displacement Power Factor (cos ϕ) near unity (> 0.98)
Switching on input supply L1, L2, L3 (power-ups) ≥ 15 hp [11 kW] maximum 1 time/ 2 min.
Environment according to EN60664-1 overvoltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100.000 RMS sym-
metrical Amperes, 500/600/690 V maximum.
Motor output (U, V, W):
Output voltage 0-100% of supply voltage
Output frequency 0 - 800 Hz
Switching on output Unlimited
Ramp times 0.01 - 3600 sec.
Torque characteristics:
Starting torque (Constant torque) maximum 160% for 60 sec.
*
Starting torque maximum 180% up to 0.5 sec.
*
Overload torque (Constant torque) maximum 160% for 60 sec.
*
Starting torque (Variable torque) maximum 110% for 60 sec.
*
Overload torque (Variable torque) maximum 110% for 60 sec.
*Percentage relates to the nominal torque.
Digital inputs:
Programmable digital inputs 4 (6)
Terminal number 18, 19, 27
1)
, 29, 32, 33,
Logic PNP or NPN
Voltage level 0-24 V DC
Voltage level, logic'0' PNP < 5 V DC
Voltage level, logic'1' PNP > 10 V DC
Voltage level, logic '0' NPN
2)
> 19 V DC
Voltage level, logic '1' NPN
2)
< 14 V DC
Maximum voltage on input 28 V DC
Pulse frequency range 0-110 kHz
(Duty cycle) Min. pulse width 4.5 ms
Input resistance, R
i
approximately 4 kΩ
VLT
®
Automation Drive FC 300
Instruction Manual High Power
5. General Specifications
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark.
111
5
