3.6. Connection Examples
3.6.1. Start/Stop
Terminal 18 = Par. 5-10 [8]
Start
Terminal 27 = Par. 5-12 [0]
No operation
(De-
fault
coast inverse
)
Terminal 37 = Safe stop (where available!)
3.6.2. Pulse Start/Stop
Terminal 18 = Par. 5-10 [9]
Latched start
Terminal 27= Par. 5-12 [6]
Stop inverse
Terminal 37 = Safe stop (where available!)
VLT
®
Automation Drive FC 300
Instruction Manual High Power
3. How to Install
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark.
65
3
