VLT
®
FCD Series
■ Operation & Display
001
001 Language
(LANGUAGE)
Value:
✭English (ENGLISH)
[0]
German (DEUTSCH)
[1]
French (FRANCAIS)
[2]
Danish (DANSK)
[3]
Spanish (ESPANOL)
[4]
Italian (ITALIANO)
[5]
Function:
This parameter is used to choose the language to
be shown in the display whenever the LCP control
unit is connected.
Description of choice:
There is a choice of the languages shown. The fac-
tory setting may vary.
002
002 Local/remote operation
(OPERATION SITE)
Value:
✭Remote operation (REMOTE)
[0]
Local operation (LOCAL)
[1]
Function:
There is a choice of two different modes of operation
of the frequency converter; Remote operation [0] or
Local operation [1]. See also parameter 013 Local
control if Local operation [1] is selected.
Description of choice:
If Remote operation [0] is selected, the frequency
converter is controlled via:
1. the control terminals or via serial communication.
2. The [START] key. This cannot, however, override
stop commands transmitted via the digital inputs
or via serial communication.
3. The [STOP/RESET] and [JOG] keys, on the con-
dition that these are active.
If Local operation [1], is selected, the frequency con-
verter is controlled via:
1. the [START] key. This cannot, however, override
stop commands via the digital inputs (see param-
eter 013 Local control).
2. The [STOP/RESET] and [JOG] keys, on the con-
dition that these are active.
3. The [FWD/REV] key, on the condition that is has
been selected as active in parameter 016 Local
reversing, and that parameter 013 Local control is
set at Local control and open loop [1] or Local
control as parameter 100 [3]. Parameter 200 Out-
put frequency range is set at Both directions.
4. parameter 003 Local reference where the refer-
ence can be set using the [+] and [-] keys.
5. an external control command that can be con-
nected to the digital inputs (see parameter 013
Local control).
NB!:
The [JOG] and [FWD/REV]
keys are located on the LCP control unit.
003
003 Local reference
(LOCAL REFERENCE)
Value:
Par.013 Local control must be set to [1] or [2]:
0-f
MAX
(par. 202)
✭ 000,000.000
Par. 013 Local control must be set to [3] or [4] and
parameter 203 Reference/feedback range to [0]:
Ref
MIN
- Ref
MAX
(par. 204-205)
✭ 000,000.000
Par. 013 Local control must be set to [3] or [4] and
parameter 203 Reference/feedback range to [1]:
- Ref
MAX
- + Ref
MAX
(par. 204-205)
✭ 000,000.000
Function:
In this parameter, the local reference can be set
manually. The unit of the local reference depends on
the configuration selected in parameter 100 Configu-
ration.
Description of choice:
In order to protect the local reference, parameter
002 Local/remote operation must be set to Local op-
eration [1]. Local reference cannot be set via serial
communication.
■ Setup configuration
There is a choice of four Setups (parameter Setups),
which can be programmed independently of one
another. The active Setup can be selected in param-
eter 004 Active Setup. When an LCP control unit is
connected, the active Setup number will be appear
in the display under “Setup”. It is also possible to
preset the frequency converter to Multisetup, so that
it is possible to shift Setups using the digital inputs
or serial communication. Setup shift can be used in
a plant in which, for example, one Setup is used for
daytime operation and another one at night time.
In parameter 006 Setup copying it is possible to
copy from one Setup to another. Using parameter
007 LCP copy all Setups can be transferred from
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.04.A1.02 - VLT is a registered Danfoss trade mark
48
