Danfoss VLT Micro Drive FC 51 Series Quick Guide

1.5 Parameter Overview
Parameter Overview
0-** Operation/Display
0-0* Basic Settings
0-03 Regional Settings
0-04 Oper. State at Power-up
(Hand)
[0] Resume
*[1] Forced stop, ref=old
[2] Forced stop, ref=0
0-1* Set-up Handling
0-10 Active Set-up
*[1] Set-up 1
[2] Set-up 2
[9] Multi Set-up
0-11 Edit Set-up
*[1] Set-up 1
[2] Set-up 2
[9] Active Set-up
0-12 Link Set-ups
[0] Not Linked
*[20] Linked
0-31 Custom Readout Min Scale
0.00–9,999.00 * 0.00
0-32 Custom Readout Max Scale
0.00–9999.00 * 100.0
0-4* LCP
0-40 [] Key on LCP
[0] Disabled
*[1] Enabled
0-41 [Off / Reset] Key on LCP
[0] Disable All
*[1] Enable All
[2] Enable Reset Only
0-42 [] Key on LCP
[0] Disabled
*[1] Enabled
0-5* Copy/Save
0-50 LCP Copy
*[0] No copy
[1] All to LCP
[2] All from LCP
[3] Size indep. from LCP
0-51 Set-up Copy
*[0] No copy
[1] Copy from Set-up 1
[2] Copy from Set-up 2
[9] Copy from Factory Set-up
0-6* Password
0-60 (Main) Menu Password
0–999 * 0
0-61 Access to Main/Quick Menu
w/o Password
*[0] Full access
[1] LCP: Read Only
[2] LCP:No Access
1-** Load/Motor
1-0* General Settings
1-00 Configuration Mode
*[0] Speed open-loop
[3] Process
1-01 Motor Control Principle
[0] U/f
*[1]
1-03 Torque Characteristics
*[0] Constant torque
[2]
1-05 Local Mode Configuration
[0] Speed Open-loop
*[2] As config in par. 1-00
1-2* Motor Data
1-20 Motor Power [kW] [HP]
[1] 0.09 kW/0.12 HP
[2] 0.12 kW/0.16 HP
[3] 0.18 kW/0.25 HP
[4] 0.25 kW/0.33 HP
[5] 0.37 kW/0.50 HP
[6] 0.55 kW/0.75 HP
[7] 0.75 kW/1.00 HP
[8] 1.10 kW/1.50 HP
[9] 1.50 kW/2.00 HP
[10] 2.20 kW/3.00 HP
[11] 3.00 kW/4.00 HP
[12] 3.70 kW/5.00 HP
[13] 4.00 kW/5.40 HP
[14] 5.50 kW/7.50 HP
[15] 7.50 kW/10.00 HP
[16] 11.00 kW/15.00 HP
[17] 15.00 kW/20.00 HP
[18] 18.50 kW/25.00 HP
[19] 22.00 kW/29.50 HP
[20] 30.00 kW/40.00 HP
1-22 Motor Voltage
50–999 V *230–400 V
1-23 Motor Frequency
1-24 Motor Current
0.01–100.00 A *Motortype dep.
1-25 Motor Nominal Speed
100–9,999 rpm *Motortype dep.
1-29
*[0] Off
[2] Enable
[3] Complete with rotating motor
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs)
[Ohm] * Dep. on motor data
1-33 Stator Leakage Reactance
(X1)
[Ohm] * Dep. on motor data
1-35 Main Reactance (Xh)
[Ohm] * Dep. on motor data
1-5* Load Indep. Setting
1-50 Motor Magnetization at 0
Speed
0–300% * 100%
1-52 Min Speed Norm. Magnet.
[Hz]
0.0–10.0 Hz * 0.0 Hz
1-55 U/f Characteristic - U
0–999.9 V
1-56 U/f Characteristic - F
0–400 Hz
1-6* Load Depen. Setting
1-60 Low Speed Load Compen-
sation
0–199% * 100%
1-61 High Speed Load Compen-
sation
0–199% * 100%
1-62 Slip Compensation
-400–399% * 100%
1-63 Slip Compensation Time
Constant
0.05–5.00 s * 0.10 s
1-7* Start Adjustments
1-71
0.0–10.0 s * 0.0 s
1-72 Start Function
[0] DC Hold/delay time
[1] DC brake/delay time
*[2] Coast/delay time
1-73
*[0] Disabled
[1]
1-8* Stop Adjustments
1-80 Function at Stop
*[0] Coast
[1] DC hold
1-82 Min Speed for Funct. at Stop
[Hz]
0.0–20.0 Hz * 0.0 Hz
1-9* Motor Temperature
1-90 Motor Thermal Protection
*[0] No protection
[1] Thermistor warning
[2] Thermistor trip
[3] Warning
[4] Trip
1-93 Thermistor Resource
*[0] None
[1] Analog input 53
[6] Digital input 29
2-** Brakes
2-0* DC Brake
2-00 DC Hold Current
0–150% * 50%
2-01 DC Brake Current
0–150% * 50%
2-02 DC Braking Time
0.0–60.0 s * 10.0 s
2-04 DC Brake Cut-in Speed
0.0–400.0 Hz * 0.0 Hz
2-1* Brake Energy Funct.
2-10 Brake Function
*[0] Off
[1] Resistor brake
[2] AC brake
2-11 Brake Resistor (ohm)
Min/Max/default: Power size dep.
2-14 Brake Voltage reduce
0–Power size dep.* 0
2-16 AC Brake, Max current
0–150% * 100%
2-17 Overvoltage Control
*[0] Disabled
[1] Enabled (not at stop)
[2] Enabled
2-2* Mechanical Brake
2-20 Release Brake Current
0.00–100.0 A * 0.00 A
2-22 Activate Brake Speed [Hz]
0.0–400.0 Hz * 0.0 Hz
3-** Reference / Ramps
3-0* Reference Limits
3-00 Reference Range
*[0] Min. - Max.
[1] -Max - +Max
3-02 Minimum Reference
-4,999–4,999 * 0.000
3-03 Maximum Reference
-4,999–4,999 * 50.00
3-1* References
3-10 Preset Reference
-100.0–100.0% * 0.00%
3-11 Jog Speed [Hz]
0.0–400.0 Hz * 5.0 Hz
3-12 Catch up/Slow-down Value
0.00–100.0% * 0.00%
3-14 Preset Relative Reference
-100.0–100.0% * 0.00%
3-15 Reference Resource 1
[0] No function
*[1] Analog Input 53
[2] Analog input 60
[8] Pulse input 33
[11] Local bus ref
[21] LCP Potentiometer
3-16 Reference Resource 2
[0] No function
[1] Analog in 53
*[2] Analog in 60
[8] Pulse input 33
*[11] Local bus reference
[21] LCP Potentiometer
3-17 Reference Resource 3
[0] No function
[1] Analog Input 53
[2] Analog input 60
[8] Pulse input 33
*[11] Local bus ref
[21] LCP Potentiometer
3-18 Relative Scaling Ref.
Resource
*[0] No function
[1] Analog Input 53
[2] Analog input 60
[8] Pulse input 33
[11] Local bus ref
[21] LCP Potentiometer
3-4*
3-40
*[0] Linear
[2]
3-41
0.05–3600 s * 3.00 s (10.00 s
1)
)
3-42
0.05–3600 s * 3.00 s (10.00 s
1)
)
3-5*
3-50
*[0] Linear
[2]
3-51
0.05–3600 s * 3.00 s (10.00 s
1)
)
3-52
0.05–3,600 s * 3.00 s (10.00 s
1)
)
3-8* Other Ramps
3-80
0.05–3,600 s * 3.00 s (10.00 s
1)
)
3-81 Quick Stop Time
0.05–3,600 s * 3.00 s (10.00 s
1)
)
1)
M4 and M5 only
Quick Guide Quick Guide
MG02B922 Danfoss A/S © Rev. 2014-02-27 All rights reserved. 11
