Danfoss VLT Micro Drive FC 51 Series Quick Guide

1.8 General Technical Data
Protection and features
•
Electronic thermal motor protection against overload.
•
Temperature monitoring of the heatsink ensures that the adjustable frequency drive trips in case of overtem-
perature.
•
The adjustable frequency drive is protected against short-circuits between motor terminals U, V, W.
•
When a motor phase is missing, the adjustable frequency drive trips and issues an alarm.
•
When a line phase is missing, the adjustable frequency drive trips or issues a warning (depending on the load).
•
Monitoring of the intermediate circuit voltage ensures that the adjustable frequency drive trips when the
intermediate circuit voltage is too low or too high.
•
The adjustable frequency drive is protected against ground faults on motor terminals U, V, W.
Line power supply (L1/L, L2, L3/N)
Supply voltage 200–240 V ±10%
Supply voltage 380–480 V ±10%
Supply frequency 50/60 Hz
Max. temporary imbalance between line phases 3.0% of rated supply voltage
True Power Factor ≥0.4 nominal at rated load
Displacement Power Factor (cosφ) near unity (>0.98)
Switching on input supply L1/L, L2, L3/N (power-ups) maximum 2 times/min.
Environment according to EN60664-1 Overvoltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/480 V
maximum.
Motor output (U, V, W)
Output voltage 0–100% of supply voltage
Output frequency 0–200 Hz (VVC
plus
), 0–400 Hz (u/f)
Switching on output Unlimited
Ramp times 0.05–3,600 s
Cable lengths and cross-sections
Max. motor cable length, shielded/armored (EMC-compatible installation) 50 ft [15 m]
Max. motor cable length, non-shielded/unarmored 164 ft [50 m]
Max. cross-section to motor, line power*
Connection to load sharing/brake (M1, M2, M3) 0.25 in [6.3 mm] insulated Faston plugs
Max. cross-section to load sharing/brake (M4, M5) 16 mm
2
/6 AWG
Maximum cross-section to control terminals, rigid wire 1.5 mm
2
/16 AWG (2x0.75 mm
2
)
Maximum cross-section to control terminals, flexible cable 1 mm
2
/18 AWG
Maximum cross-section to control terminals, cable with enclosed core 0.5 mm
2
/20 AWG
Minimum cross-section to control terminals 0.00039 in
2
[0.25 mm
2
]
* See chapter 1.7 Specifications for more information!
Quick Guide Quick Guide
18 Danfoss A/S © Rev. 2014-02-27 All rights reserved. MG02B922
