Technical Features
Quick Reference Guide 13
TECHNICAL FEATURES
Electrical Features
Battery Type 2150 Li-Ion battery pack
Time of recharge max. 4 hours with external power supply
max. 10 hours with Host power
Operating autonomy
(continuous reading)
60,000 reads (typical)
Display
(Only available with some
models)
LCD 4 lines x 16 chars
Programmable font and backlight
Indicators Good Read LED green
Good Read Spot green
Beeper
Laser Features
M8300 M8300-AR
Power (max) in mW 0.9 mW 1.3 mW
Light Source VLD in the range between 630~680 nm
Scan Rate 35 ± 5 scans/sec
Reading Field Width
(typical) see reading diagram
Max. Resolution 0.076 mm (3 mils) 0.19 mm (7.5 mils)
PCS minimum
(Datalogic Test Chart)
15% 25%
Scan Angle 42° 13.5° 0.7
Laser Safety Class 2 (EN 60825-1 / CDRH)
Radio Features European Models USA Models
Radio Frequency 433.92 MHz 910 MHz
Bit rate 19200 baud 36800 baud
Range (in open air) 50 m 30 m
System Configuration BC-80X0 STARGATE™
Max. number of devices
per base station
32 255
Max. number of devices
in the same reading area
2000
Environmental Features
Working Temperature -20° to +50 C / -4 to +122 °F
Storage Temperature -20° to +70 C / -4 to +158 °F
Humidity 90% non condensing
Drop resistance
(on concrete) 2 m
Protection Class IP65 (IP64 for models with display)
Mechanical Features
Weight (with batteries) about 400 g (14.10 oz)
Dimensions 212 x 109 x 71 mm (8.34 x 4.29 x 2.79 in)
Material Polycarbonate molded with rubber
