Selecting the Interface Type
4 PowerScan™ PD8300
Selecting the Interface Type
Upon completing the physical connection between the reader and its host, proceed
directly to Interface Selection below for information and programming for the in-
terface type the reader is connected to (for example: RS-232, Keyboard Wedge,
USB, etc.) and scan the appropriate barcode to select your system’s correct interface
type.
Interface Selection
Select one of the interface codes according to your application.
USB Interface Selection
* When configuring USB-COM, the relevant files and drivers must be installed from the USB
Device Installation software. Go to www.datalogic.com.
USB-KBD
Ì$+UA03$-:Î
USB-KBD-ALT-MODE
Ì$+UA04$-@Î
USB-COM*
Ì$+UA02$-4Î
USB-IBM-Hand Held
Ì$+UA01$-.Î
USB-IBM Table top
Ì$+UA00$-(Î
USB KBD-APPLE
Ì$+UA05$-FÎ
To Next Page
