Technical Features
Quick Reference Guide 9
Technical Features
PowerScan™ PD8300
Electrical Features
PowerScan™ PD8300
Power Supply
4 to 30 VDC
Max. Consumption: 0.076 mm (3 mils)
@ 4V
@5V
@30V
Sleep mode
420 mA
310 mA
62 mA
4 mA
Scan Rat 35 ± 5 scans/sec
Reading Indicators
Good Read LED (green)
Good Read Spot (green), Beeper
Optical Features
Reading Field
(Typical performance at 20ºC /
68ºF on high quality barcodes)
97.8 cm (38.5 in)
@ 40 mils
Max. Resolution 0.076 mm (3 mils)
PCS 15%
Laser Features
Power (max) 0.9 mW
Scan Angle 42°
Laser Safety Class Class 2 EN 60825-1/CDRH
Environmental Features
Working Temperature -30 °C to + 50 °C / -22° to +122 °F
Storage Temperature -30 °C to + 70 °C / -22° to +158 °F
Humidity 90% non condensing
Drop Resistance IEC 68-2-32 Test ED 2 m
Protection Class IP65
Mechanical Features
Weight (without cable) about 295 g (10.4 oz)
Cable Length 2 m (6 ft 6 in)
