Quick Reference Guide 1
PowerScan™ PD953X
Description
The PowerScan™ 953X is a feature-rich and rugged area
imager reader. It is offered in several different models to
better fit the different needs of each customer.
The table below shows the unique features of each model:
General Features
Model P/N Optical feature
PD953X Standard optic, standard and low density codes
PD953X-HP
Autofocus optic, High, standard and low density
codes, wide angle
PD953X-HPE
Autofocus optic, High, standard and low density
codes, wide angle
PD953X-DPM
High Density optic, high and medium density
codes, DPM (laser, ink jet and dot peen)
Omni-directional
Operating
To read a symbol or capture an image, you
simply aim the reader and pull the trigger.
Since the PowerScan™ PD953X is a powerful
omni-directional reader, the orientation of the
symbol is not important.
Decoding
Thanks to powerful algorithms, PowerScan™
PD953X reliably decodes all major 1D (linear)
barcodes, 2D stacked codes (such as PDF417),
2D matrix symbols (such as DataMatrix), postal
codes (such as POSTNET, PLANET). The data
stream — acquired from decoding a symbol —
is rapidly sent to the host. The reader is imme-
diately available to read another symbol.
Formatting and
Concatenating
The string of a decoded code may be pro-
cessed according to either a simple or
advanced data formatting and be concate-
nated.
