Interface Selection
12 QuickScan™ Mobile
Interface Selection
Follow the procedure to configure the interface required by your application.
Multi-standard interface models:
·USB Interface
· RS-232 Interface
·Wedge Interface
·Pen Interface
USB Interface Configuration
The USB interface is compatible with:
- Windows 98 (and later)
- Mac SO 8.0 (and later)
- 4690 Operating System
START-UP
As with all USB devices, upon connection, the Host performs several checks
by communicating with the cradle. Before the cradle is ready, the correct USB
driver must be loaded.
For all systems, the correct USB driver for the default USB-KBD interface is
included in the Host Operating System and will either be loaded automatically
or will be suggested by the O.S. and should therefore be selected from the
dialog box (the first time only).
You can now read codes with the associated QuickScan Mobile reader. At this
point you can read the USB interface configuration code according to your
application. Load drivers from the O.S. (if requested). When configuring the
USB-COM interface, the relevant files and drivers must be installed from the
USB Device Installation software which can be downloaded from the web site:
http://www.datalogic.com
.
The cradle is ready.
Successive start-ups will automatically recognize the previously loaded
drivers.
