Daymak MAX User Manual

15
Charging the Tofino X 36V
First take the charger that came with your Tono X 36V and plug it into the the wall. Once
you have done that locate the charging port of the Tono X 36V located on the right side
of the frame.
When the bike is charging the charger will glow red. When the unit is fully charged the
charger will glow green and then your bike is ready to go.
Warning
Do not leave the Tono X 36V charging for long periods of me aer it is fully charged.
Once the bike is charged unplug it ASAP.
1) This is your charge port, plug your charger into here and the other end into a 110V
outlet.

Daymak MAX Specifications

General

Category	Electric Scooter
Motor Power	500W
Battery Type	Lithium-Ion
Battery Voltage	48V
Battery Capacity	12Ah
Max Speed	32 km/h
Weight Capacity	120 kg
Brakes	Disc Brakes
Tire Size	10 inches
Charging Time	4-6 hours
Range	40 km
Weight	23 kg
