14
Section 3
386
Rear Panel Connections
• Connect the source to the desired 1/4” TRS or XLR input.
• Connect the AES/EBU or S/PDIF output of the 386 and run into the
AES/EBU or S/PDIF input interface of the DAW (CPU).
Front Panel Digital Output Features
1). Use the METER switch to select digital output metering.
2). Use the DITHER switch to select the desired dither algorithm.
3). Use the SHAPE switch to select the desired noise-shaping algorithm.
4). Use the SAMPLE RATE switch to select the correct sampling rate.
5). Use the WORD LENGTH switch to select the correct word length.
6). Use the OUTPUT FORMAT switch to select the appropriate digital output format.
