Product features
Product specications
The following table shows the technical specications of the PowerEdge R740xd2:
Features Specications
Form Factor 2U
Scalability (Sockets) 2 sockets
Processors Intel® Xeon® Scalable processor server CPU
Processor TDP Up to 140W
Processor Cores Up to 22
Chipset Intel® C621 chipset
VGA Embedded in BMC (integrated VGA chip)
Memory technology 8GB/16GB/32GB DDR4
DIMMs per socket (total DIMMs) 16 DIMM slots
DIMM Type RDIMM
Memory Bandwidth 2666 MT/s
PCIe slots Up to 5 x Gen3 slots (x16)
PCIe Gen Gen 3
Power supplies
• Platinum: 750W or 1100W
• HVDC: 750W or 1100W hot plug power supplies with full redundancy option
• 6 fans with N +1 redundancy
USB Front 2 x USB 2.0 : Micro USB iDRAC x1 + 1 x USB 2.0
USB Rear 2 x USB 3.0
USB Internal 1 x USB 3.0
Serial Port Yes
Video Yes, 1x standard VGA (Rear)
SATA ports (from PCH) Up to 12 SATA ports. 2 rear drives onboard SATA Support
Disk Drives
• 3.5" hard disk drives/2.5" SSD drives with 3.5" carrier, hot pluggable
• Front drive bays: Up to 24 x 3.5” SAS/ SATA (HDD) max 336TB, or up 16 x 3.5”
SAS/SATA (HDD) plus up to 8 x 2.5” SAS (SSD) max 285.44TB
• Rear drive bays: Up to 2 x 3.5” SAS SATA (HDD) max 28TB or up to 2 x 2.5” SAS
(SSD) drives max 15.36TB
Storage controllers
• Internal Controllers: PERC H730P, H330
• Software RAID (SWRAID): S140
• Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs, 240GB or 480GB
6
