Dell 13 7000 2-in-1 User Manual

Removing the speakers
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
Remove the base cover.
Procedure
1 Disconnect the speaker cable from the system board.
2 Lift the left speaker o the palm-rest assembly.
3 Remove the speaker cable from the routing guides on the battery.
4 Peel o the tape that secures the speaker cable to the palm-rest assembly.
30

Dell 13 7000 2-in-1 Specifications

General

Display Size	13.3 inches
Wireless	802.11ac Wi-Fi, Bluetooth 4.0
Resolution	1920 x 1080 pixels
Processor	Intel Core i5 or i7
RAM	8GB
Operating System	Windows 10
Ports	2 x USB 3.0, 1 x HDMI, 1 x SD card reader, 1 x headphone/microphone combo jack
