Your Dell Projector 7
About Your Projector
WARNING: Safety Instructions
1
Do not use the projector near appliances that generate a lot of heat.
2
Do not use the projector in areas where there is an excessive amount of dust. The
dust may cause the system to fail and the projector will automatically shutdown.
3
Ensure that the projector is mounted in a well-ventilated area.
4
Do not block the ventilation slots and openings on the projector.
5
Ensure the projector operates between ambient temperatures (0 ºC to 35 ºC).
6
Do not try to touch the ventilation outlet as it can become very hot after the
projector has been turned on or immediately after it is turned off.
1 Control panel
2 Zoom tab and Focus ring
3 Lens
4 IR receivers
5 Lens cap
6 Quick-release button
7 Lamp cover
8 Mounting holes for ceiling mount: Screw hole M3 x 4.6mm depth.
Recommended torque <8 kgf-cm
9 Front adjuster foot
10 Mounting hole for tripod: Insert nut 1/4"*20 UNC
11 Tilt adjustment wheel
5
2
3
4
1
6
7
9
10
11
8
