Connecting Your Projector
WARNING: Before you begin any of the procedures in this section, follow the
Safety Instructions as described on page 7.
1 Mini USB (type B) remote
connector
7 Audio input connector
2 VGA-A output
(monitor loop-through)
8 Security cable slot
3 VGA-A input (D-sub) connector 9 Audio output connector
4 VGA-B input (D-sub) connector 10 Composite video connector
5 RS232 control port 11 Power cord connector
6 S-video connector
3 4 51 2 6 7
8
11
910
