Dell 1510X User Manual

Troubleshooting Your Projector 65
Guiding Signals
Projector
Status
Description
Control Buttons Indicator
Power Menu Others
TEMP
(Amber)
LAMP
(Amber)
Standby mode Projector in Standby mode. Ready to
power on.
BLUE
Flashing
OFF OFF OFF OFF
Warming up
mode
Projector takes some time to warm up
and power on.
BLUE BLUE BLUE OFF OFF
Lamp on Projector in Normal mode, ready to
display an image.
Note: The OSD menu is not accessed.
BLUE BLUE OFF OFF OFF
Cooling mode Projector is cooling to shutdown. BLUE OFF OFF OFF OFF
Power Saving
mode
Power Saving mode has been activated.
The projector will automatically enter
standby mode, if an input signal is not
detected in two hours.
AMBER
Flashing
OFF OFF OFF OFF
Cooling before
Power Saving
mode
The projector takes 60 seconds to cool
down before entering Power Saving
mode.
AMBER OFF OFF OFF OFF
Projector
overheated
Air vents might be blocked or ambient
temperature may be above 35ºC. The
projector automatically shuts down.
Ensure that the air vents are not blocked
and that the ambient temperature is
within operational range. If the problem
persists, contact Dell.
OFF OFF OFF AMBER OFF
Lamp
overheated
The lamp is overheated. The air vents
may be blocked. The projector
automatically shuts down. Turn the
display on again after the projector cools
down. If the problem persists, contact
Dell.
BLUE OFF OFF AMBER OFF
Lamp driver
overheated
The lamp driver is overheated. The air
vents may be blocked. The projector
automatically shuts down. Turn the
display on again after the projector cools
down. If the problem persists, contact
Dell.
AMBER OFF OFF AMBER OFF
Fan breakdown One of the fans has failed. The projector
automatically shuts down. If the problem
persists, contact Dell.
ÒFF OFF OFF
AMBER
Flashing
OFF
Lamp driver
breakdown
The lamp driver has failed. The projector
automatically shuts down. Unplug the
power cord after three minutes then turn
the display on again. If this problem
persists, contact Dell.
AMBER
Flashing
OFF OFF OFF
AMBER
Flashing
Color Wheel
breakdown
Color wheel cannot start. The projector
has failed and the projector
automatically shuts down. Unplug the
power cord after three minutes and then
turn on the projector. If this problem
persists, contact Dell.
BLUE OFF OFF
AMBER
Flashing
AMBER
Flashing

Dell 1510X Specifications

General

Native aspect ratio	4:3
Projection distance	1.2 - 10 m
Projection technology	DLP
Contrast ratio (typical)	2100:1
Screen size compatibility	30.8 - 307 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-35 - 40 °
Zoom capability	Yes
Focal length range	18.2 - 21.8 mm
Lamp power	225 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
DVI port	No
Composite video in	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	2
CardBus PCMCIA slots quantity	0
RS-232 ports	-
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC 4.43, NTSC J, NTSC M, PAL 60, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, PAL Nc, SECAM B, SECAM D, SECAM G, SECAM K1, SECAM L
Supported graphics resolutions	1024 x 768 (XGA)
RMS rated power	8 W
Placement	Desktop
Product type	Standard throw projector
Product color	Black
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	287 W
Power consumption (PowerSave)	15 W
Battery type	2 x AAA
Noise level	35 dB
Noise level (economic mode)	32 dB
Storage temperature (T-T)	0 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Cables included	VGA

Weight and Dimensions

Depth	202 mm
Width	296.5 mm
Height	87.9 mm
Weight	2360 g
