Dell 1610HD User Manual

Using Your Projector 19
3
Using Your Projector
Turning Your Projector On
NOTE: Turn on the projector before you turn on the source (computer, DVD
player, etc.). The Power button light blinks blue until pressed.
1 Remove the lens cap.
2 Connect the power cord and appropriate signal cables. For information about
connecting the projector, see "Connecting Your Projector" on page 9.
3 Press the Power button (see "Using the Control Panel" on page 23 to locate the
Power button).
4 Turn on your source (computer, DVD player, etc.).
5 Connect your source to the projector using the appropriate cable. See
"Connecting Your Projector" on page 9 for instructions to connect your source to
the projector.
6 By default, the input source of projector is set to VGA-A. Change the input source
of projector if necessary.
7 If you have multiple sources connected to the projector, press the Source button
on the remote control or control panel to select the desired source. See "Using the
Control Panel" on page 23 and "Using the Remote Control" on page 26 to locate
the
Source button.
Turning Your Projector Off
NOTICE: Unplug the projector after properly shutting down as explained in the
following procedure.
1 Press the Power button.
NOTE: The "Press Power Button to Turn off Projector" message will appear
on the screen. The message disappears after 5 seconds or you can press the
Menu button to clear it.
2 Press the Power button again. The cooling fans continue to operate for 120
seconds.

Dell 1610HD Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1.2 - 10 m
Projection technology	DLP
Supported aspect ratios	16:9, 16:10
Contrast ratio (typical)	2100:1
Screen size compatibility	36.3 - 362 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-35 - 40 °
Lamp power	225 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
Full HD	No
HD-Ready	Yes
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, NTSC 4.43, NTSC J, NTSC M, PAL, PAL B, PAL D, PAL G, PAL H, PAL L, PAL M, PAL N, PAL Nc, SECAM, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L
Supported graphics resolutions	1280 x 800, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
RMS rated power	8 W
Number of built-in speakers	1
HDMI version	1.3
HDMI connector type	Full-size
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	287 W
Power consumption (PowerSave)	15 W
Power consumption (economy mode)	219 W
Storage temperature (T-T)	0 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	0 - 80 %
Throw ratio	1.28 -1.536
Focal length range	18.2 - 21.8 mm
Aperture range (F-F)	2.4 - 2.66
Noise level	35 dB
Noise level (economic mode)	32 dB
Placement	Desktop
Product type	Standard throw projector
Product color	Black

Weight and Dimensions

Depth	202 mm
Width	296.5 mm
Height	87.9 mm
Weight	2360 g
