Dell 1610HD User Manual

Using Your Projector 27
7 Video mode The projector has preset configurations that are
optimized for displaying data (presentation slides)
or video (movies, games, etc.).
Press the Video Mode button to toggle between
Presentation mode, Bright mode, Movie mode,
sRGB, or Custom mode.
Pressing the Video Mode button once will show the
current display mode. Pressing the Video Mode
button again will switch between modes.
8
Mouse up
U
Press to move to previous page.
NOTE: The USB cable must be connected if
you want to use the Page Up feature.
9
Mouse down
V
Press to move to next page.
NOTE: The USB cable must be connected if
you want to use the Page Down feature.
10 Freeze Press to pause the screen image.
11 Blank screen Press to hide/unhide the image.
12 Information
Press to provide projector native resolution
information.
13 S-Video Press to choose S-Video source.
14
Up
Press to navigate through the On-Screen Display
(OSD) Menu items.
15
Left
Press to navigate through the On-Screen Display
(OSD) Menu items.
16 Menu Press to activate the OSD.
17
Volume up
Press to increase the volume.
18 Source Press to switch between Analog RGB, Composite,
Component (YPbPr, via VGA), HDMI, and
S-video source.
19
Volume down
Press to decrease the volume.
20 Keystone adjustment
+
Press to adjust image distortion caused by tilting the
projector (+40/-35 degrees).
21
Keystone adjustment - Press to adjust image distortion caused by tilting the
projector (+40/-35 degrees).

Dell 1610HD Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1.2 - 10 m
Projection technology	DLP
Supported aspect ratios	16:9, 16:10
Contrast ratio (typical)	2100:1
Screen size compatibility	36.3 - 362 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-35 - 40 °
Lamp power	225 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
Full HD	No
HD-Ready	Yes
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, NTSC 4.43, NTSC J, NTSC M, PAL, PAL B, PAL D, PAL G, PAL H, PAL L, PAL M, PAL N, PAL Nc, SECAM, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L
Supported graphics resolutions	1280 x 800, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
RMS rated power	8 W
Number of built-in speakers	1
HDMI version	1.3
HDMI connector type	Full-size
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	287 W
Power consumption (PowerSave)	15 W
Power consumption (economy mode)	219 W
Storage temperature (T-T)	0 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	0 - 80 %
Throw ratio	1.28 -1.536
Focal length range	18.2 - 21.8 mm
Aperture range (F-F)	2.4 - 2.66
Noise level	35 dB
Noise level (economic mode)	32 dB
Placement	Desktop
Product type	Standard throw projector
Product color	Black

Weight and Dimensions

Depth	202 mm
Width	296.5 mm
Height	87.9 mm
Weight	2360 g
