VESA, 1280 x 800 61.6 59.81 83.5 +/-
VESA, 1280 x 1024 64.0 60.0 135.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1440x900 55.9 60 106.5 -/+
Electrical Specification
Video input signals Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at 50 ohm input impedance
Synchronization input signals Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG (Composite SYNC on green)
AC input voltage/frequency/current 100 to 240 VAC / 60 or 50 Hz + 3 Hz / 1.5A (Max.)
Inrush current 120V:30A (Max.)
240V:60A (Max.)
Physical Characteristics
Connector type 15-pin D-subminiature, blue connector; DVI-D, white connector
Signal cable type Digital: Detachable, DVI-D, Solid pins, shipped detached from the monitor
Analog: Detachable, D-Sub, 15pins, shipped attached to the monitor
Dimensions (with stand):
Height (Compressed) 12.54 inches (318.60 mm)
Height (Extended) 17.27 inches (438.60 mm)
Width 17.43 inches (442.75 mm)
Depth 7.38 inches (187.41 mm)
Dimensions: (without stand)
Height
11.50 inches (292.10 mm)
Width
17.43 inches (442.75 mm)
Depth
2.36 inches (60.00 mm)
Stand dimensions:
Height
14.23 inches (361.55 mm)
Width
14.46 inches (367.40 mm)
Depth
7.38 inches (187.41 mm)
Weight with packaging 16.26 lbs (7.375 kg)
Weight with stand assembly and cables 13.10 lbs (5.94 kg)
Weight without stand assembly
(For wall mount or VESA mount considerations - no cables)
8.49 lbs (3.85 kg)
Weight of stand assembly 3.40 lbs (1.54 kg)
Environmental Characteristics
