Dell 2355dn User Manual

316
NOTE: Refer to Mac OS User’s Guide that came with your computer for further information on Mac OS error
messages.
Common Linux Problems
“Fail To Print”, “A printer
timeout error occurred.”
messages appear.
These messages may appear during printing. Just keep waiting until the machine finishes
printing. If the message appears in standby mode or after printing has been completed,
check the connection and/or whether an error has occurred.
Condition Suggested solutions
Condition Suggested solutions
The printer doesn’t print. • Check if the printer driver is installed in your system. Open MFP configurator and switch to
the Printers tab in Printers configuration window to look at the list of available printers.
Ensure that your printer is displayed on the list. If not, please, invoke Add new printer wizard
to set up your device.
• Check if the printer is started. Open Printers configuration and select your printer on the
printers list. Look at the description in the Selected printer pane. If its status contains
“(stopped)” string, please, press the
Start button. After that normal operation of the printer
should be restored. The “stopped” status might be activated when some problems in printing
occurred. For instance, this could be an attempt to print document when MFP port is claimed
by a scanning application.
• Check if the MFP port is not busy. Since functional components of MFP (printer and scanner)
share the same I/O interface (MFP port), the situation of simultaneous access of different
“consumer” application to the same MFP port is possible. To avoid possible conflicts, only
one of them at a time is allowed to gain control over the device. The other “consumer” will
encounter “device busy” response. You should open MFP ports configuration and select the
port assigned to your printer. In the Selected port pane you can see if the port is occupied by
some other application. If this is the case, you should wait for completion of the current job or
should press Release port button, if you are sure that the present owner is not functioning
properly.
• Check if your application has special print option such as “-oraw”. If “-oraw” is specified in
the command line parameter then remove it to print properly. For Gimp front-end, select
“print”
“Setup printer” and edit command line parameter in the command item.

Dell 2355dn Specifications

General

Current rating	3.5 A
Fax compatibility	ITU-T G3
Dimensions (WxDxH)	465 x 445 x 460 mm
Energy saving mode	Yes
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Digital sender	No
Printing colors	Black
Maximum duty cycle	80000 pages per month
Recommended duty cycle	1000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	199 copies
Time to first copy (black, normal)	15 s
Copy speed (black, normal quality, A4)	33 cpm
Scan to	E-mail, File, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	8
Input color depth	24 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	4800 x 4800 DPI
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Multi-Purpose tray input capacity	50 sheets
Envelopes sizes	10, C5, C6, DL
Maximum print size	210 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 90 g/m²
Display	LCD
Display diagonal	4.3 \
Market positioning	Business
Standard interfaces	Ethernet, USB 1.1, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	-
Supported network protocols (IPv4)	TCP(DHCP, DNS, 9100, LPR, SNMP, HTTP, HTTPS, IPPS, LDAPSIPSec), EtherTalk
Internal memory	256 MB
Maximum internal memory	512 MB
Sound power level (standby)	52 dB
Sound pressure level (quiet mode)	30 dB
AC input voltage	220 - 240 V
Power consumption (off)	0 W
Power consumption (standby)	57 W
Power consumption (PowerSave)	11.36 W
Power consumption (average operating)	502 W
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled software	SmartThru Office2 Dell Scan Manager Dell Toner Management System Dell Printer Status Monitor Printer Setting Utility Set IP Address Utility Firmware Upgrade Utility Dell Printer Configuration Web Tool (EWS)
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Certification	ROHS, EN 55022:2006 +A1:2007 / CISPR 22:2005 + A1:2005, EN 61000-3-3; EN55024; FCC CFR Title 47, Part 15 Class B / Part 68; ICES-003, Issue 4, CE GOST, SABS
