NOTE: Ensure that the panel has a clean and smooth surface to rest on to prevent damage.
5. Disconnect the display cable from the display panel assembly and lift the display panel away from the system.
NOTE: Do not remove the metal brackets from the panel.
Installation display panel
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the display panel and provides a visual representation of the installation procedure.
64 Removing and installing components
