109
4. Special features
Using advanced print features
XPS printer driver: used to print XPS file format.
The XPS printer driver can be installed only on Windows Vista OS or
higher.
You can install the XPS printer driver when you insert the software CD
into your CD-ROM drive. When you install the Dell software, the XPS
printer driver is automatically installed.
1
Printing to a file (PRN)
You will sometimes need to save the print data as a file.
1
Check the Print to file box in the Print window.
2
Click Print.
3
Type in the destination path and the file name, and then click OK.
For example, c:\Temp\file name.
If you type in only the file name, the file is automatically saved in My
Documents, Documents and Settings, or Users. The saved folder may
differ, depending on your operating system or the application you are
using.
2
Understanding special printer features
You can use advanced printing features when using your machine.
To take advantage of the printer features provided by your printer driver, click
Properties or Preferences in the application’s Print window to change the
print settings. The machine name, that appears in the printer properties window
may differ depending on the machine in use.
Some menus may not appear on the display depending on options or
models. If so, it is not applicable to your machine.
Select the Help or click the button from the window or press F1 on
your keyboard and click on any option you want to know about (see
"Using help" on page 35).

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell B1260dn and is the answer not in the manual?

Dell B1260dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Resolution color600 x 600 DPI
Maximum resolution1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)28 ppm
Maximum duty cycle20000 pages per month
Number of print cartridges1
Page description languagesPCL 6, SPL
Memory typeDDR2
Processor modelARM 11
Total input capacity250 sheets
Total output capacity150 sheets
Maximum input capacity251 sheets
Maximum print size210 x 297 mm
Duplex media weight60 - 120 g/m²
Paper tray media typesBond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper, Transparencies
Paper tray media weight60 - 163 g/m²
ISO A-series sizes (A0...A9)A4
Multi-Purpose Tray media weight60 - 220 g/m²
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supportedMac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Linux operating systems supportedFedora 11, Fedora 12, Fedora 13, Fedora 14, Fedora 15, Fedora 6, Fedora 7, Fedora 8, Fedora 9, SuSE Linux 10, SuSE Linux 11, Ubuntu 10.04, Ubuntu 8.04, Ubuntu 8.10, Ubuntu 9.04, Ubuntu 9.10
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Power consumption (printing)- W
Display-
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)348 x 338 x 197 mm
