NOTE: Damaging pins during removal of the processor can cause damage to the processor.
4. Repeat the above steps to remove the second processor (if available) from the computer.
To verify if your computer has dual processor slots, see the System Board components.
Installing the Processor
1. Place the processor in its socket.
2. Replace the processor cover.
NOTE: The processor cover is secured by two levers. They have icons that indicate which lever
needs to be opened first and which lever closes first.
3. Slide the first lever sideways into the retention hook to secure the processor.
4. Repeat step '3' to slide the second lever into the retention hook.
5. Install:
a. heatsink assembly
b. computer cover
6. Follow the procedures in After Working Inside Your Computer.
System Board Components
The following image displays the system board components .
36
