Dell E2223HV User Manual

46 │ Troubleshooting
Product-specific problems
Specific symptoms Possible solutions
Screen image is too small • Check the Aspect Ratio setting in the Display settings OSD.
• Reset the monitor to Factory Settings (Factory Reset).
Cannot adjust the monitor
with the buttons on the
bottom of the panel
• Turn off the monitor, unplug the power cord, plug it back, and then turn on
the monitor.
• Check if the OSD menu is locked. If yes, press and hold the Exit button
(button 4) for four seconds to unlock.
No input signal when user
controls are pressed
• Check the signal source. Ensure that the computer is not in standby or
sleep mode by moving the mouse or pressing any key on the keyboard.
• Check if the video cable is plugged in properly. Disconnect and reconnect
the video cable if necessary.
• Reset the computer or video player.
The picture does not fill the
entire screen
• Due to different video formats (aspect ratio) of DVDs, the monitor may
display in full screen.
• Run the built-in diagnostics.

Dell E2223HV Specifications

General

Panel type	VA
Pixel pitch	0.249 x 0.249 mm
Screen shape	Flat
Pixel density	103 ppi
Response time	12 ms
Backlight type	LED
Display diagonal	21.45 \
Heat dissipation	64.79 BTU/h
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 75 Hz
Maximum refresh rate	60 Hz
Response time (fast)	8 ms
Horizontal scan range	30 - 83 kHz
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	54.48 cm
Display brightness (typical)	250 cd/m²
LED indicators	Power
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
Doesn't contain	PVC/BFR
Sustainability certificates	ENERGY STAR, RoHS, TCO
DisplayPorts quantity	0
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	19 W
Power consumption (off)	0.3 W
Power consumption (typical)	12.13 W
Package weight	4010 g
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Office
Cables included	AC, VGA
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (side)	12.8 mm
Depth (with stand)	171 mm
Width (with stand)	504.26 mm
Height (with stand)	384.17 mm
Weight (with stand)	2900 g
Bezel width (bottom)	16.9 mm
Depth (without stand)	49.64 mm
Height (without stand)	295.38 mm
Weight (without stand)	2260 g
