Before you install an operating system
NOTE: Before you install an operating system, ensure that the switch has the most current ONIE and firmware version. To
upgrade your switch, go the Drivers and Downloads page for your switch as www.dell.com/support.
After turning on the Z9432F-ON switch, it goes through a power-on self-test (POST). POST runs every time that the switch is
initialized and checks the hardware components to determine if the switch is fully operational before booting. After POST, the
switch uses the Grub bootloader.
To select an entry, use the up and down arrow keys. Press Enter to select an ONIE menu entry.
Grub bootloader example
GNU GRUB version 2.02~beta2+e4a1fe391
+-------------------------------------------------+
|*ONIE: Install OS |
| ONIE: Rescue |
| ONIE: Uninstall OS |
| ONIE: Update ONIE |
| ONIE: Embed ONIE |
| EDA-DIAG |
| |
+-------------------------------------------------+
NOTE: To access ONIE, use the RJ45 or Micro-USB console port.
ONIE example
ONIE: Install OS
For downloading and installing an OS from a URL
Starts ONIE with ONIE Discovery Service
(factory default boot)
ONIE: Rescue
Starts ONIE without ONIE Discovery Service
Useful for running Diagnostics manually
ONIE: Uninstall OS
Restore to factory defaults erases any installed OS
ONIE: Update ONIE
For downloading and updating ONIE from a URL
ONIE: Embed ONIE
For downloading and updating ONIE from a URL and erases any installed OS
During the initial setup, the switch boots to ONIE Install. ONIE Install boots with ONIE Discovery to the console, ONIE:.
NOTE: For more information, see the Open Networking Hardware Diagnostic Guide at www.dell.com/support.
NOTE: After you have securely installed and turned on the Z9432F-ON switch, to configure your switch, see your third-
party ONIE-compatible operating system or the Dell EMC operating system documentation.
Topics:
• Check your switch
• ONIE service discovery
9
Before you install an operating system 45
