 Camera
Dell™Inspiron™1011ServiceManual
Removing the Camera
Replacing the Camera



Removing the Camera

1. Follow the instructions in Before You Begin.

2. Remove the display bezel (see Removing the Display Bezel).

3. Remove the screw that secures the camera to the display cover.

4. Disconnect the camera cable from the connector.

5. Remove the camera board.
Replacing the Camera

1. Connect the camera cable to the connector.

2. Align the screw hole on the camera board with the screw hole on the display cover.

3. Replace the screw that secures the camera to the display cover.

4. Replace the display bezel (see Replacing the Display Bezel).
Back to Contents Page

WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on the back of the computer).
CAUTION: Onlyacertifiedservicetechnicianshouldperformrepairsonyourcomputer.DamageduetoservicingthatisnotauthorizedbyDell™
is not covered by your warranty.
CAUTION: To help prevent damage to the system board, remove the main battery (see Removing the Battery) before working inside the
computer.
1
camera
2
screw
3
camera cable connector


