Dell Inspiron 3420 User Manual

Keyboard 17
Replacing the Keyboard
1 Follow the instructions in "Before You Begin" on page 9.
2 Slide the keyboard cable into the connector on the system board. Press
down on the connector latch to secure the keyboard cable to the connector
on the system board.
3 Slide the tabs on the keyboard into the slots on the palm rest.
4 Gently press around the edges of the keyboard to lock the four tabs
securing the keyboard.
5 Close the display and turn the computer over.
6 Replace the battery (see "Replacing the Battery" on page 14).
1 keyboard cable 2 keyboard
1
2

Dell Inspiron 3420 Specifications

General

CPU	Intel Core i3/i5/i7 (varies by model)
Memory	Up to 8GB DDR3
Storage	Up to 500GB HDD
Display	14.0 inch HD (1366x768)
Graphics	NVIDIA GeForce GT 620M
Operating System	Windows 7/8
Battery	6-cell Lithium Ion
Ports	USB 2.0, USB 3.0, HDMI, VGA, Ethernet, Headphone/Microphone combo jack
Wireless	Wi-Fi 802.11 b/g/n, Bluetooth 4.0
