Next steps
1. Replace the M.2 SSD.
2. Replace the battery.
3. Replace the base cover.
4. Replace the microSD card.
5. Follow the procedure in after working inside your computer.
Inner frame
Removing the inner frame
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the microSD card.
3. Remove the base cover.
4. Remove the battery.
5. Remove the WLAN card.
6. Remove the M.2 SSD.
7. Remove the M.2 SSD bracket.
Steps
1. Unroute the WLAN antenna cables.
48
Disassembly and reassembly
