Dell Latitude 7210 User Manual

Keys Navigation
Tab Moves to the next focus area.
Esc Moves to the previous page until you view the main screen. Pressing Esc in the main screen displays a message
that prompts you to save any unsaved changes and restarts the system.
Boot Sequence
Boot sequence enables you to bypass the System Setup–defined boot device order and boot directly to a specific device (for example:
optical drive or hard drive). During the Power-on Self-Test (POST), when the Dell logo appears, you can:
• Access System Setup by pressing F2 key
• Bring up the one-time boot menu by pressing F12 key.
The one-time boot menu displays the devices that you can boot from including the diagnostic option. The boot menu options are:
• Removable Drive (if available)
• STXXXX Drive
NOTE: XXXX denotes the SATA drive number.
• Optical Drive (if available)
• SATA Hard Drive (if available)
• Diagnostics
NOTE: Choosing Diagnostics, displays the ePSA diagnostics screen.
The boot sequence screen also displays the option to access the System Setup screen.
System setup options
NOTE:
Depending on the tabletcomputerlaptop and its installed devices, the items listed in this section may or may not
appear.
General options
Table 20. General options
Option Description
System Information
This section lists the primary hardware features of your computer.
The options are:
• System Information
• Memory Configuration
• Processor Information
• Device Information
Battery Information Displays the battery status and the type of AC adapter connected
to the computer.
Boot Sequence
Allows you to change the order in which the computer attempts to
find an operating system.
The options are:
• Windows Boot Manager—Enable or disable the Windows
Boot Manager option.
• Boot List Option—You can add, delete, and view the boot
options.
Advanced Boot Options
Enable or disable the UEFI Network Stack option.
System setup 19

Dell Latitude 7210 Specifications

General

Display diagonal	12.3 \
Touchscreen type	Capacitive
Display resolution	1920 x 1280 pixels
Anti-reflective coating	Yes
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	LPDDR3-SDRAM
SSD interface	PCI Express
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Internal storage capacity	256 GB
Rear camera type	Single camera
Video capturing speed	30 fps
Video recording modes	1080p
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	5 MP
Speaker power	2 W
Number of built-in speakers	2
Bluetooth version	5.1
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Mobile network connection	No
HDMI ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Device type	Tablet PC
Form factor	Convertible (Detachable)
Product color	Black, Grey, Silver
Assisted GPS (A-GPS)	-
Platform	Windows
Trial software	Microsoft Office
Operating system language	Multilingual
Operating system architecture	64-bit
Battery voltage	8.9 V
Battery capacity	- mAh
Battery life (max)	- h
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	2.25 A
AC adapter output voltage	20 V
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor threads	8
Processor codename	Comet Lake
Processor frequency	1.6 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	46 x 24 mm
Number of execution units	24
Processor boost frequency	4.2 GHz
PCI Express configurations	1x4, 2x2, 1x2+2x1, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.8 GHz
Graphics card	UHD Graphics
Processor ARK ID	195436
Processor socket	BGA 1528
Repairability index	6.9

Weight and Dimensions

Depth	9.35 mm
Width	292 mm
Height	208.8 mm
Weight	935 g
Package depth	103 mm
Package width	359.3 mm
Package height	348.3 mm
Package weight	2480 g
