Dell Latitude 7210 User Manual

Option Description
Fn Lock Options
Allows you to let hot key combinations Fn + Esc toggle the primary behavior of F1–F12, between their
standard and secondary functions. If you disable this option, you cannot toggle dynamically the primary
behavior of these keys. By default, the Fn Lock option is enabled.
Select one of the following options:
• Lock Mode Disable/Standard
• Lock Mode Enable/Secondary—enabled by default
Fastboot
Allows you to speed up the boot process by bypassing some of the compatibility steps.
Select one of the following options:
• Minimal—enabled by default
• Thorough
• Auto
Extended BIOS POST
Time
Allows you to create an additional preboot delay.
Select one of the following options:
• 0 seconds—enabled by default
• 5 seconds
• 10 seconds
Full Screen Logo
Allows you to display full screen logo, when your image matches screen resolution. By default, the Enable
Full Screen Logo option is disabled.
Warnings and Errors
Allows you to select different options to either stop, prompt and wait for user input, continue when
warnings are detected but pause on errors, or continue when either warnings or errors are detected
during the POST process.
Select one of the following options:
• Prompt on Warnings and Errors—enabled by default
• Continue on Warnings
• Continue on Warnings and Errors
Virtualization support
Table 29. Virtualization Support
Option Description
Virtualization
This option specifies whether a Virtual Machine Monitor (VMM) can use the additional hardware
capabilities that are provided by the Intel Virtualization technology. By default, the Enable Intel
Virtualization Technology option is enabled.
VT for Direct I/O
Enables or disables the Virtual Machine Monitor (VMM) from using the additional hardware
capabilities that are provided by the Intel Virtualization technology for direct I/O. By default, the
Enable VT for Direct I/O option is enabled.
Wireless options
Table 30. Wireless
Option Description
Wireless Switch
Allows to set the wireless devices that can be controlled by the
wireless switch.
The options are:
26 System setup

Dell Latitude 7210 Specifications

General

Display diagonal	12.3 \
Touchscreen type	Capacitive
Display resolution	1920 x 1280 pixels
Anti-reflective coating	Yes
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	LPDDR3-SDRAM
SSD interface	PCI Express
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Internal storage capacity	256 GB
Rear camera type	Single camera
Video capturing speed	30 fps
Video recording modes	1080p
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	5 MP
Speaker power	2 W
Number of built-in speakers	2
Bluetooth version	5.1
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Mobile network connection	No
HDMI ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Device type	Tablet PC
Form factor	Convertible (Detachable)
Product color	Black, Grey, Silver
Assisted GPS (A-GPS)	-
Platform	Windows
Trial software	Microsoft Office
Operating system language	Multilingual
Operating system architecture	64-bit
Battery voltage	8.9 V
Battery capacity	- mAh
Battery life (max)	- h
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	2.25 A
AC adapter output voltage	20 V
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor threads	8
Processor codename	Comet Lake
Processor frequency	1.6 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	46 x 24 mm
Number of execution units	24
Processor boost frequency	4.2 GHz
PCI Express configurations	1x4, 2x2, 1x2+2x1, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.8 GHz
Graphics card	UHD Graphics
Processor ARK ID	195436
Processor socket	BGA 1528
Repairability index	6.9

Weight and Dimensions

Depth	9.35 mm
Width	292 mm
Height	208.8 mm
Weight	935 g
Package depth	103 mm
Package width	359.3 mm
Package height	348.3 mm
Package weight	2480 g
